XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear

I'm Online Chat Now

XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear

XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear
XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear

Large Image :  XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear

Product Details:
Place of Origin: Ningbo China
Brand Name: Tianan Electric
Certification: IEC62271& GB 3906
Model Number: XGTD7-(12/24)40.5
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Pending
Packaging Details: Wooden cases
Delivery Time: 45 days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 3000sets per year
Detailed Product Description
Rated Frequency: 50/60 Hz Rated Current: 630/1250/1600/2000/2500 A
Rated Voltage: 12/24/40.5 KV Degree Of Protection: HV:IP67 LV:IP4X
Weight: 1000~1600 Kg Altitude: <5000m Above The Sea Level
Highlight:

hv circuit breaker

,

high voltage vacuum circuit breaker

XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear



General introduction

XGN (XGTD7)-(12/24) 40.5 series indoor gas-insulated metal-clad switchgear (hereinafter called "C-GIS cabinet") is a switchgear which uses a spring-operated vacuum circuit breaker, electrically operated three station isolation / earthing switch,CT/PT lightning arrester as the main components, and completely seals all HV conductors in the metal-clad enclosure with gas as the insulating medium.

The product has features of flexible combinations, great safety, complete interlocking logic as well as extensibility, miniaturization and free for maintenance. So that it was commonly used in infrastructure construction for power station, power substation, movable transformer pack, buildings that have the 35kV or below nominal voltage. Especially for some sever environment like high altitude, heavy pollution and high humidity.

The product quality assurance is based on researching, developing designing and producing required by quality system and continues to improve. So it is completely complying with the newest version or revised version of following standard, but not limited to them.GB3906 3.6 ~ 40.5 kVAC metal-enclosed switchgear and control equipment

GB/T 11022 Common technical requirements for HV switchgear and control equipment standardsDL/T 404 3.6 ~ 40.5 kVAC metal-enclosed switchgear and control equipment

GB1984 HVAC circuit breaker

GB 1985 HVAC isolation switch and earthing switch

GB 11032 AC gapless metal oxides surge arrester

IEC62271-200 AC metal-enclosed switchgear and control equipment with rated voltage above 1kV, 52kV and below

EN 50181 Plug-in bushing for equipment with rated voltage of 1kV~52kV and current of 250A~2500A



Type and designation

   XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear 0



Technical parameter

XGTD7-(12/24)40.5 Indoor Gas Insulation Mental-clad Switchgear 1
