Product Details:
Payment & Shipping Terms:
|
| Act Fuse: | Act Fuse | Rated Voltage: | 12 Kv~24kv |
|---|---|---|---|
| Altitude: | Up To 3,000m Above Sea Level | Environment: | Indoor |
| Special Condition: | Depends On The Customer | Rated Current: | 630A~1000A |
| Rated Short Time Continual Time: | 4 S | Test Equipment: | IEC Standard |
| Typical Products: | Protection Fuse | Frequency: | 50 Hz |
| High Light: | high voltage fuse,drop out fuse |
||
Data of technical
>>A, XRNT-24----32A
Rated voltage: 24KV
Rated current of fuse: 32A
Rated current of melter: 1, 2, 4, 6.3, 10, 16, 20, 25, 31.5, 32 A
Dimension: 442*51mm
>>B, XRNT-24---100A
Rated voltage: 24KV
Rated current of fuse: 100A
Rated current of melter: 40, 50, 63, 71, 80, 100 A
Dimension: 442*76mm
>>C, XRNT-24----200A
Rated voltage: 24KV
Rated current of fuse: 200A
Rated current of melter: 125, 160, 200 A
Dimension: 442*88mm
Other Information
Notes for ordering
Please offer the followings while ordering:
>A, Type and name of products;
>B, Rated voltage and rated current;
>C, Breaking current and quantity;
>D, Please indicate if details of special requests while ordering.
Parameters
| TYPE | RLF-3 | RLF-3 |
| Rated voltage(kv) | 10-15 | 10-15 |
| Rated current(A) | 100 | 200 |
| Breaking Current(A) | 6000 | 8000 |
| Impulse voltage(KV) | 110 | 110 |
| Power-frequency withstand voltage(KV) | 40 | 40 |
| Creepage distance(mm) | 340 | 340 |
| Weight(kg) | 7.5 | 7.5 |
| Dimensions(cm) | 49*27*11 | 49*27*11 |
