Product Details:
Payment & Shipping Terms:
|
| Voltage Rating: | 11KV12kv | Cooling Method: | Oil-immersed Type Transformer |
|---|---|---|---|
| Capacity: | 1250kVA | Frequency: | Power Frequency |
| High Light: | Compact Substations Transformers 1000kva,Three Phase Compact Substations Transformers |
||
Main technical parameter of transformer
Voltage combination
Rated voltage of HV side: 12kV
Rated voltage of LV side: 0.27kV, 0.3kV, 0.315kV, 0.4kV
HV tapping range+5% or + 2x2.5%
Connecting symbol: Dyn11 or Yyn0
Condensation controller and other auxiliary equipment can be added in the body as per clients' requests.
Insulation class: A class
No. of phases: three
Note: As per different requirement from client, the capacity of transformer can be customized.
Product technical parameter
11kV oil immersed load switch
Table 1
S/N |
Name | Unit | Parameter | ||
| 1 | Rated voltage | KV | 12 | ||
| 2 | Rated current | A | 315 | 630 | |
| 3 | Rated frequency | Hz | 50 | ||
| 4 | Rated short-circuit withstand current | kA/2s | 12.5 | 20 | |
| 5 | Rated peak withstand current | kA | 31.5 | 50 | |
| 6 | Mechanical endurance | times | 2000 | ||
| 7 | 1 min power withstand voltage (phase-to-phase, phase-to-earth) | kV | 42 | ||
| 8 | Lightning impulse level (phase-to-phase, phase-to-earth) | KV | 75 | ||
11kV Fuse
Table 2
| Rated voltage | Fuse rated current A | Rated Max. breaking current kA | Remark |
| 15.5 | 63, 80,100,125,150 | 50 | off line |
Lightning arrester
Table 3
| Rated voltage | Continuous operating voltage | DC reference voltage (1mA) | Nominal discharging current | Nominal discharging current residual | 2ms square-wave current withstand value |
| 17kV | 13.6kV | ≥24kV | 5kA(peak value) | ≤45kV (peak value) | ≥250A(peak value) |
